Cups, pressure rings & spacers continued...

Optional accessories

223-68-1 – Pressure ring

76-379-2 – Threaded

shaft ring

Fits both aluminum DSP and

GSP wing nuts. Prevents metal-

to-metal contact, significantly

increasing clamping force

(height: 0.97 in.).

Prevents cone or collet from

sliding off the balancer shaft

when removing assembly from

the balancer. Not recommended

unless same cone is used

repeatedly.

HammerHead

Top-Dead-Center (TDC)

clip-weight placement laser system

The HammerHead

laser projects laser lines on the rim

flange for precise clip-weight application. HammerHead

also includes an overhead light to illuminate the work area.

HammerHead can be ordered with Touch/LCD balancers in

group configurations or as a line item add-on:

20-2166-1 For any LCD-series balancer

20-2892-1 For any Touch-series balancer

* Printer model may vary.

20-2143-1 Ink jet color

printer and side storage

support kit

Printer package and storage kits*

RFT02 shown with optional

HammerHead

laser system

Factory

or ﬁ eld

installed

Factory

or ﬁ eld

installed
